HD50Z
General Purpose
X/Y axes : 450 x 350 mm
Z axis : 345 mm
W axis Travel + Manual Guide Travel : 200 + 150 mm
Specification
HD50Z
Work table size (WxD)
600 x 300 mm
X/Y axes travel
450 x 350 mm
Z axis travel
345 mm
W axis Travel + Manual Guide Travel
200 + 150 mm
Electrode size
Ø 0.3 ~ Ø 3.0 mm
Maxi. electrode length
400 mm
Maxi. workpiece size
990 x 460 x 350 mm
Maxi. workpiece weight
450 kg
Machine weight
1730 kg
Max. Machining Current
48 A
Input power
4.0 KVA
Machine dimension
2036 x 2075 x 2290 mm
Accessory
Standard Accessories
Electrode Chuck Ø0.3mm~Ø3.0mm x 1
Electrode Guide Ø1.0mm x 1
Electrode Brass Tube Ø1.0mm x 20pcs
Work Lamp x 1
80L Stainless Water Filter Tank
Tools Box x 1
Paper Filter PW-40-2 300 x 29 x 500mm 10μm x 1pcs
Paper Filter PP 10inch 5μm x 1pcs
Parallel Pad x 2
Water Seal
Options
Electrode Chuck Ø3.1mm~Ø6.0mm
CE
Finish Stop Device
Air Chuck
